Fume Incinerator & Heat Recovery System
Process Flow
Burning Chamber
Heat Exchanger for Waste Pre-Heating.
Blower (*Blower waster Gas from Oven)
Heat Exchanger for Fresh Air
Blower (* Filter * Hot Air to Oven)
Heat Exchanger for Fresh Air
Blower (* Filter * Hot Air to Oven)
Specification
The above specification is for reference only. Customers’ specification is available upon requests.
| Item & Type | FS-80 |
| Incinerate Capacity | 6,000 N M³/Hr(100 N M³/min) ~ 36,000 N M³/Hr(600 M³/min) |
| Solvent Release | 85 L/Hr ~ 500 L/Hr (Total) |
| Heating Fuel | Liquid natural gas @ 105 Kpa supply Pressure (about 9,000 Kacl/ M³) or Liquid propane (LPG) @ 105 Kpa supply Pressure (about 23,303 Kal/ M³) |
| Power Supply | 380/220 Volt, 50HZ, 3Phase, 4 wire. |
- The above specification is for reference only.
- ALUMAX has the right to make any change.
